Rechargeable Li Polymer Batteries 902535 3.7V 800mAh 2.96wh Power Lithium Batteries

Brand Name:	RESKY
Model Number:	LP902535
MOQ:	100pcs
Price:	Negotiable
Packaging Details:	Paper box
Payment Terms:	Western Union,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, RoHS, MSDS, Un38.3

Document:

Nominal Capacity:

800mAh

Charging Current:

Continuous Discharging Current:

Max Discharging Current:

Weight:

Cycle Life:

500cycles

Warranty:

12months

Shipping:

UPS, DHL, FedEx, TNT, By Air, By Sea, Special Line

Connector:

Jst, Molex....

Specification:

9*25*35mm

Supply Ability:

50000pcs/day

Highlight:

rechargeable lithium polymer battery 3.7V

902535 LiPo battery 800mAh

3.7V power lithium battery with warranty

Product Description

Rechargeable Li Polymer Batteries 902535 3.7V 800mAh 2.96wh Power Lithium Batteries

Specifications

NO.	Items	Specifications
1	Batteries	3.7V 800mAh LiPo battery
2	Charge voltage	4.2V
3	Nominal voltage	3.7V
4	Nominal capacity	800mAh 0.2C Discharge
5	Charge current	Standard Charging: 0.5C Rapid charge: 1.0C
6	Standard Charging method	0.5C CC(constant current)charge to 4.2V, then CV(constant voltage 4.2V)charge till charge current decline to ≤0.05C
7	Charging time	Standard Charging: 2.75hours(Ref.) Rapid charge: 2hours(Ref.)
8	Max.charge current	1.0C
9	Max.discharge current	1.0C
10	Discharge cut-off voltage	2.5V 0.25V(0.2C)
11	Operating temperature	Charging: 0°C ~45°C Discharging: 0°C ~45°C
12	Storage temperature	-10°C~ +45°C
13	Dimension	Length: 35±2mm (not including tabs) Width: 25±0.5mm Thickness: 9±0.2mm
14	Drop Test	The cell is to be dropped from a height of meter twice onto concrete ground. No fire, no leakage
15	Cycle time	≥500times

Applications

Consumer Electronics

Bluetooth Speakers: Provides stable power as a built-in battery for portable Bluetooth speakers.

GPS Positioning Devices: Powers in-vehicle or portable GPS trackers.

Smart Wearables: Provides battery life for devices like smart bracelets and children's watches.

Industrial and Small Electronic Devices

Medical Instruments: Devices requiring small batteries, such as electronic thermometers and blood pressure monitors.

Toys and Models: Used in small electronic devices like remote-controlled toys and electric fences.

Outdoor Equipment: Portable lighting devices like camping lanterns and night fishing lights.
