Lithium Polymer Battery Cell

Power Lithium Ion Cell 703048 3.7v 1000mAh 3.7wh Rechargeable Lithium Li-Ion Polymer Battery

All Category

RC Accessories

Mrs. Alice

alice@szresky.com

0086 13530058480

0086 13530058480

Contact Now

Power Lithium Ion Cell 703048 3.7v 1000mAh 3.7wh Rechargeable Lithium Li-Ion Polymer Battery

Brand Name:	RESKY
Model Number:	LP703048
MOQ:	10pcs
Price:	Negotiable
Packaging Details:	Paper box
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, RoHS, MSDS, Un38.3

Model NO.:

LP703048

Discharge Rate:

Low Discharge Rate

Shape:

Square Battery

Nominal Capacity:

1000mAh

Weight:

Cycle Life:

500cycles

Warranty:

12months

Specification:

7*30*48mm

HS Code:

8507600090

Supply Ability:

100000PCS/Day

Supply Ability:

50000pcs/day

Highlight:

Rechargeable Lithium Polymer Battery

1000mAh Lithium Polymer Battery

3.7v Lithium Polymer Battery

Product Description

Power Lithium Ion Cell 703048 3.7v 1000mAh 3.7wh Rechargeable Lithium Li-Ion Polymer Battery

Product Specifications

Attribute	Value
Model NO.	LP703048
Discharge Rate	Low Discharge Rate
Shape	Square Battery
Nominal Capacity	1000mAh
Weight	9g
Cycle Life	500cycles
Warranty	12months
Specification	73048mm
HS Code	8507600090
Supply Ability	100000PCS/Day

Technical Details

NO.	Items	Specifications
1	Batteries	3.7v 1000mah lipo battery
2	Charge voltage	4.2V
3	Nominal voltage	3.7V
4	Nominal capacity	1000mAh 0.2C Discharge
5	Charge current	Standard Charging: 0.5C Rapid charge: 1.0C
6	Standard Charging method	0.5C CC(constant current)charge to 4.2V, then CV(constant voltage 4.2V)charge till charge current decline to ≤0.05C
7	Charging time	Standard Charging: 2.75hours(Ref.) Rapid charge: 2hours(Ref.)
8	Max.charge current	1.0C
9	Max.discharge current	1.0C
10	Discharge cut-off voltage	2.5V±0.25V(0.2C)
11	Operating temperature	Charging: 0°C ~45°C Discharging: 0°C ~45°C
12	Storage temperature	-10°C~ +45°C
13	Dimension	Length: 48±2mm (not including tabs) Width: 30±0.5mm Thickness: 7±0.2mm
14	Drop Test	The cell is to be dropped from a height of meter twice onto concrete ground. No fire, no leakage
15	Cycle time	≥500times

Applications

Electrical Toothbrush
MP4
MID
Monitor
Backup power
Portable DVD
POS machine
Desk video
Motor drill
Digital camera

Key Features

Physical Specifications & Form Factor

Dimensions: Precise dimensions of 7mm (thickness) × 30mm (width) × 48mm (length) (703048 code, where numbers represent thickness × width × length in mm). This slim, rectangular shape is ideal for space-constrained applications like wearable devices, portable electronics, or compact IoT gadgets.

Weight: Lightweight design, typically weighing ~30g (varies slightly by manufacturer), enabling portable devices to remain ergonomic and easy to handle.

Flexible Structure: Unlike rigid lithium-ion batteries, the polymer electrolyte allows minor flexibility in shape (within safe limits), accommodating curved or non-uniform device interiors without damage.

Electrical Performance Parameters

Charge Voltage: Maximum charging voltage of 4.2V (constant-current/constant-voltage charging profile). Charging beyond this voltage risks overheating or capacity degradation.

Discharge Cutoff Voltage: Minimum safe discharge voltage of 2.75V (to prevent deep discharge, which irreversibly damages the cell).

Continuous Discharge Current: Rated for 1C (1000mA) continuous discharge (varies by manufacturer; some versions may support up to 2C (2000mA) for short durations, ideal for devices with occasional high-power bursts, e.g., wireless earbuds during audio playback).

Product Images
