Lithium Polymer Battery Cell

Solar Lithium Polymer Battery Cell 3.7V 604060 654060 2000mAh Batteries For Portable Exchange Devices

All Category

Lithium Polymer Battery Cell

RC Lithium Battery

Li-Ion Battery Pack

Lithium Polymer Battery Pack

Heated Lithium Battery

Electric Bike Battery

RC Balance Charger

Rechargeable Battery Charger

RC Accessories

Mrs. Alice

alice@szresky.com

0086 13530058480

0086 13530058480

Contact Now

Solar Lithium Polymer Battery Cell 3.7V 604060 654060 2000mAh Batteries For Portable Exchange Devices

Brand Name:	RESKY
Model Number:	LP654060
MOQ:	10pcs
Price:	Negotiable
Packaging Details:	Paper box
Payment Terms:	Western Union,T/T

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

China

Certification:

CE, RoHS, MSDS, Un38.3

Shape:

Square Battery

Electrolyte:

Li(Nicomn)O2

Rechargeable:

Chargeable

Nominal Capacity:

2000mAh

Weight:

25g

Lead Time:

3-10workdays

OEM Service:

Yes

Specification:

6.5*40*60mm

HS Code:

8507600090

Supply Ability:

100000PCS/Day

Supply Ability:

50000pcs/day

Highlight:

654060 Lithium Polymer Battery Cell

2000mAh Lithium Polymer Battery Cell

604060 Lithium Polymer Battery Cell

Product Description

Solar Lithium Polymer Battery Cell 3.7V 604060/654060 2000mAh

High-performance rechargeable lithium polymer battery cells designed for portable exchange devices, featuring excellent energy density and safety characteristics.

Technical Specifications

Item	Specification
Battery Type	3.7V 2000mAh LiPo Battery
Charge Voltage	4.2V
Nominal Voltage	3.7V
Nominal Capacity	2000mAh (0.2C Discharge)
Charge Current	Standard: 0.5C Rapid: 1.0C
Standard Charging Method	0.5C CC charge to 4.2V, then CV charge till current ≤0.05C
Charging Time	Standard: 2.75 hours (Ref.) Rapid: 2 hours (Ref.)
Max. Discharge Current	1.0C
Discharge Cut-off Voltage	2.5V±0.25V (0.2C)
Operating Temperature	Charging: 0°C to 45°C Discharging: 0°C to 45°C
Storage Temperature	-10°C to +45°C
Dimensions	60±2mm (L) × 40±0.5mm (W) × 6.5±0.2mm (T) (excluding tabs)
Cycle Life	≥500 cycles

Key Features & Advantages

High Energy Density: Compact size with substantial power capacity
Excellent Safety: Dual IC chips protect against short-circuit, overcharge, overcurrent, and overload
Long Cycle Life: 500+ charge/discharge cycles
Fast Charging: Full charge in 2-3 hours at 4.2V per cell
Advanced Construction: Injection technology enhances stability
Rugged Design: Passes 1-meter drop tests without fire or leakage
Environmental Compliance: Meets CE, ROHS, SGS, MSDS, UN38.3, IEC61233 standards
