Solar Power Bank Lifepo4 Battery 25.6V 100Ah Lithium Iron Phosphate Battery Pack For Robots & AGVs

Brand Name:	RESKY
Model Number:	RSK-LFP25.6-100
MOQ:	1pcs
Price:	Negotiable
Packaging Details:	Wooden case
Payment Terms:	Western Union,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,RoHS,MSDS,Un38.3

Electrolyte:

Lifepo4

Structure:

Cell Type:

100Ah Lifepo4 Battery Cells

Motor:

2500W

Charging Cut-off Voltage:

29.2V

Charging Current:

Dishcarging Cut-off Voltage:

Continuous Discharging Current:

2560wh

Dimension:

190*292*318mm

Supply Ability:

500pcs/day

Highlight:

AGVs Solar Power Bank Lifepo4 Battery

robots Solar Power Bank Lifepo4 Battery

Lifepo4 Battery 25.6V 100Ah

Product Description

Solar Power Bank Lifepo4 Battery 25.6V 100Ah Lithium Iron Phosphate Battery Pack For Robots & AGVs

Product Attributes

Attribute	Value
Electrolyte	Lifepo4
Structure	8s1p
Cell Type	100Ah Lifepo4 Battery Cells
Motor	2500W
Charging Cut-off Voltage	29.2V
Charging Current	10A
Discharging Cut-off Voltage	20V
Continuous Discharging Current	100A
Wh	2560wh
Dimension	190292318mm

Specifications

Product name

25.6V 100Ah

Model

RSK-25.6-100

Rated Capacity

100Ah

Nominal Voltage

25.6V

Over discharge protection voltage

20V±0.05V

Over charge protection voltage

29.2V±0.05V

AC Impedance New Cell Max.(mΩ)

≤100 mΩ

Maximum Continuous Charge Current

≤10A adjustment

Maximum Continuous Discharge Current

≤50A adjustment

Maximum Pulse discharge current

≤100A adjustment

Operation Temperature Range

Charge: 0~45°C, Discharge: -20~60°C

Storage Temperature Range

Less than 1 year: -20~25°C
Less than 3 months: -20~40°C

Storage Temperature Range

Less than 30 Days: -25°C~45°C
Less than 90 Days: -25°C~30°C

Weight

Approx 30kg

Cycle Characteristic

3000 times

Advantages

High energy density and long life:

Lithium iron phosphate battery has high energy density and can provide enough energy after a single charge to support electric pallet truck for long-term handling operations, reducing the need for frequent charging and improving work efficiency.

In additional, lithium iron phosphate battery has a long cycle life. After thousands of charge and discharge cycles, the battery capacity decay remains at a low level, which means that the battery life is longer and the long-term operating cost of users is reduced.

Fast charging and high efficient charging and discharging:

Lithium iron phosphate battery supports high current charging and can complete charging in a shorter time, usually only 4 to 5 hours to fully charge, while traditional lead-acid batteries take 8 to 10 hours.

This enables electric pallet trucks to resume working status faster and improve overall operating efficiency.

High safety and stability:

Lithium iron phosphate batteries have high thermal stability and low risk of spontaneous combustion. They can maintain stable performance even under extreme conditions, ensuring the safety of electric pallet trucks during operation.

In additional, the lithium iron phosphate battery has a stable structure during the charging and discharging process, does not burn or explode, and further improves its safety.

Low maintenance cost:

Lithium iron phosphate batteries have no memory effect and can be charged and discharged at any time without special maintenance.

This reduces the maintenance cost of electric pallet trucks and reduces downtime caused by battery problems.

Wide range of application:

Lithium iron phosphate batteries are suitable for various working environments, including food, fast-moving consumer goods, cold chain logistics and other fields, and can meet the needs of different warehousing systems.

In additional, the casing of the lithium iron phosphate battery is connected by gas shielded welding and high-strength bolts to ensure its reliability and durability.

Applications

Electric Vehicles:

Suitable for commercial transportation vehicles such as logistics vehicles and heavy trucks, satisfy safety and cycle life features.

Energy storage system:

It is used in photovoltaic and wind power supporting energy storage and power grid peak shaving systems, emphasizing economics and long-term stability.

Industrial Equipment:

It is applied to robots, AGVs (automatically guided vehicles), rail transit and other scenarios that require high reliability.

Why Choose Us?

We accept small quantity order or big quantity order

We could accept any customized lithium battery pack orders

We could accept orders with different requirements

We guarantee 100% QC pass before delivery

Fast production time, we have enough stock cells

Fast solution confirmation, and quotation confirmation

Factory Pictures

Product Pictures
