Power Lithium Cell 854565 3.7V 3400mAh 12.58wh Solar Lithium Ion Polymer Battery Pack

Brand Name:	RESKY
Model Number:	LP854565
MOQ:	100pcs
Price:	Negotiable
Packaging Details:	Paper box
Payment Terms:	Western Union,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, RoHS, MSDS, Un38.3,IEC62133,ECT

Document:

Electrolyte:

Li(Nicomn)O2

Rechargeable:

Chargeable

Nominal Capacity:

3400mAh

Weight:

Cycle Life:

500cycles

Warranty:

12months

Connector:

Jst, Molex....

Original:

Shenzhen, China

OEM Service:

HS Code:

8507600090

Supply Ability:

50000pcs/day

Highlight:

3.7V lithium polymer battery

3400mAh solar battery pack

854565 lithium ion cell

Product Description

Power Lithium Cell 854565 3.7V 3400mAh 12.58wh Solar Lithium Ion Polymer Battery Pack

Product Specifications

NO.	Items	Specifications
1	Batteries	3.7V 3400mAh Lipo Battery
2	Charge voltage	4.2V
3	Nominal voltage	3.7V
4	Nominal capacity	3400mAh @ 0.2C Discharge
5	Charge current	Standard Charging: 0.5C Rapid charge: 1.0C
6	Standard Charging method	0.5C CC charge to 4.2V, then CV charge till current ≤0.05C
7	Charging time	Standard: 2.75 hours (Ref.) Rapid: 2 hours (Ref.)
8	Max. charge current	1.0C
9	Max. discharge current	1.0C
10	Discharge cut-off voltage	2.5V±0.25V (0.2C)
11	Operating temperature	Charging: 0°C ~45°C Discharging: 0°C ~45°C
12	Storage temperature	-10°C ~ +45°C
13	Dimension	Length: 65±2mm (excl. tabs) Width: 45±0.5mm Thickness: 8.5±0.5mm
14	Drop Test	1m drop onto concrete twice - No fire, no leakage
15	Cycle time	≥500 cycles

Safety Features

Energy Density: High capacity in compact size for lightweight applications
Dual IC Protection: Prevents overcharging, over-discharging, and short-circuiting
Separator Adhesion: Prevents internal shorts from physical impacts
Temperature Management: Designed to prevent thermal runaway
Overcharge/Discharge Protection: Circuits monitor and disconnect unsafe conditions
Short-Circuit Protection: Includes fuse links and current-limiting devices
Certified Compliance: Meets international safety standards (IEC/UL)
Safe Storage/Transport: Requires cool, dry conditions per regulations

Applications

Mid-sized consumer electronics devices
- 10-12-inch tablets (entry-level)
- Mid- to high-end handheld game consoles
IoT and industrial portable devices
- 4G/5G smart gateways (small and medium)
- Portable testing instruments
- Industrial remote controls (large equipment)
Outdoor and emergency equipment
- Small consumer drones (entry-level)
- Outdoor Bluetooth speakers (mid-sized)
- Emergency power supplies (mini)
Medical and healthcare equipment
- Portable ultrasound diagnostic equipment (home/basic)
- Small home oxygen concentrators

Product Images
