Rechargeable Lithium Ion Polymer Battery Cell 7244145 3.7v 5000mAh 18.5wh 30C Power

Brand Name:	RESKY
Model Number:	LP7244145SH30
MOQ:	10pcs
Price:	Negotiable
Packaging Details:	Paper box
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, RoHS, MSDS, Un38.3

Electrolyte:

Li(Nicomn)O2

Nominal Capacity:

5000mAh

Max Discharging Current:

Peak Discharging Current:

Weight:

100g±4%

Warranty:

12months

Connector:

Xt60, Xt90, T-Type, Anderson, Bullet

Specification:

7.2*45*145mm

HS Code:

8507600090

Working Voltage:

Supply Ability:

10000pcs/day

Highlight:

Lithium Ion Polymer Battery Cell 7244145

18.5wh Lithium Ion Polymer Battery Cell

3.7v 5000mAh Lithium Ion Polymer Battery

Product Description

Product Description

7244145 3.7v 5000mAh 18.5wh 30C Power Rechargeable Lithium Ion Polymer Battery Cell

NO.	Items	Specifications
1	batteries	3.7V 5000mah lipo battery
2	Charge voltage	4.2V
3	Nominal voltage	3.7V
4	Nominal capacity	5000mAh 15C Discharge
5	Charge current	Standard Charging:0.2C Rapid charge: 15C
6	Standard Charging method	0.5C CC(constant current)charge to 4.2V, then CV(constant voltage 4.2V)charge till charge current decline to ≤0.05C
7	Charging time	Standard Charging:2.75hours(Ref.) Rapid charge: 2hours(Ref.)
8	Max.charge current	0.5C
9	Max.discharge current	35.0C
10	Discharge cut-off voltage	2.5V0.25V(0.2C)
11	Operating temperature	Charging: 0 °C ~45 °C Discharging:0 °C ~45 °C
12	Storage temperature	-10°C~ +45 °C
13	Dimension	Length:145±0.5mm (not including tabs) Width:45±0.5mm Thickness:7.2±0.2mm
14	Drop Test	The cell is to be dropped from a height of meter twice onto concrete ground. No fire, no leakage
15	cycle time	≥500times

Features:

Capacity and Voltage:

Capacity: Measured in milliampere-hours (mAh), this determines how long the RC vehicle will run per charge. A higher mAh rating means longer run time.

Voltage: Determines the speed and power of the RC model. The voltage of a battery pack is the sum of the voltages of its individual cells. For example, a 2S LiPo battery pack has two cells in series, providing a voltage of around 7.4V.

Safety and Maintenance:

LiPo batteries, in particular, require careful handling to avoid overcharging, over-discharging, and short-circuiting, which can lead to fire or explosion.

It is recommended to use a charger designed for the specific type of battery and to regularly monitor the battery's health and performance.

Performance Over Time:

RC batteries gradually lose performance over time, manifesting as decreased voltage and reduced run time. Proper care and maintenance can extend the lifespan of the battery.

Pictures:
