Lithium Polymer Battery Cell

Rechargeable Lithium Polymer Battery Cell 523450 553450 603450 Lipo Battery

All Category

RC Accessories

Mrs. Alice

alice@szresky.com

0086 13530058480

0086 13530058480

Contact Now

Rechargeable Lithium Polymer Battery Cell 523450 553450 603450 Lipo Battery

Brand Name:	RESKY
Model Number:	LP553450
MOQ:	10pcs
Price:	Negotiable
Packaging Details:	Paper box
Payment Terms:	Western Union,T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE, RoHS, MSDS, Un38.3

Document:

Electrolyte:

Li(Nicomn)O2

Rechargeable:

Chargeable

Nominal Capacity:

1100mAh

Weight:

Warranty:

12months

Shipping:

UPS, DHL, FedEx, TNT, By Air, By Sea, Special Line

Connector:

Jst, Molex....

Specification:

5.5*34*50mm

Origin:

China

HS Code:

8507600090

Supply Ability:

50000pcs/day

Highlight:

Rechargeable Lithium Polymer Battery Cell

Lithium Polymer Battery Cell 523450

603450 Lipo Battery

Product Description

Rechargeable Lithium Polymer Battery Cell 523450 553450 603450 Lipo Battery

Product Specifications

Electrolyte	Li(Nicomn)O2
Rechargeable	Chargeable
Nominal Capacity	1100mAh
Weight	9g
Warranty	12 months
Shipping	UPS, DHL, FedEx, TNT, by Air, by Sea, Special Line
Connector	Jst, Molex
Specification	5.53450mm
Origin	China
HS Code	8507600090

Technical Details

1	Batteries	3.7V 1100mAh LiPo battery
2	Charge voltage	4.2V
3	Nominal voltage	3.7V
4	Nominal capacity	1100mAh @ 0.2C Discharge
5	Charge current	Standard: 0.5C Rapid charge: 1.0C
6	Standard Charging method	0.5C CC charge to 4.2V, then CV charge till current ≤0.05C
7	Charging time	Standard: 2.75 hours Rapid charge: 2 hours
8	Max. charge current	1.0C
9	Max. discharge current	1.0C
10	Discharge cut-off voltage	2.5V±0.25V (0.2C)
11	Operating temperature	Charging: 0°C ~45°C Discharging: 0°C ~45°C
12	Storage temperature	-10°C ~ +45°C
13	Dimension	Length: 50±2mm Width: 34±0.5mm Thickness: 5.5±0.2mm
14	Drop Test	1 meter drop onto concrete twice - No fire, no leakage
15	Cycle time	≥500 cycles

Capacity Enhancement Methods

Material Improvement

Optimizing the Positive Electrode Material: Increasing nickel content in nickel-cobalt-manganese ternary materials can improve specific capacity. Research continues on lithium-rich manganese-based oxides for higher theoretical capacities.

Developing Advanced Negative Electrode Materials: Silicon-based materials offer significantly higher capacity than graphite. Composite materials and surface modification techniques help address volume expansion challenges.

Battery Structure Optimization

Increasing Electrode Thickness/Area: Carefully increasing electrode dimensions allows more active material while balancing size and internal resistance constraints.

Optimizing Internal Space Utilization: Compact designs with thinner separators maximize space for active materials, improving capacity without increasing external dimensions.

Product Images
